MHERO II Specifications | Engine, Battery & Performance

MHERO II Highlights

Max. Performance

677 HP (500 kW)

Max Torque

848 Nm

Battery Size

31.7 kWh

0–100 km/h

5.2 seconds

Range – WLTC

1,113 km Max

Ground Clearance

333 mm

Intelligent All-Wheel Drive with 6 Drive Modes

Snow

Mud

Rock

Sand

Wading

Auto

Vehicle Warranty*

6 years

Drive System Warranty*

10 years

*Terms & Condition Apply

Dimensions

OVERALL

STORAGE

OFF-ROAD

Maximum Height

1,899 mm

Length

5,100 mm

Length with Storage Box

—

Wheel Base

3,005 mm

Width

1,998 mm

Trunk Volume

828 l (2,112 l)

Storage Box

—

Approach Angle

37.7º

Departure Angle

37º

Passage Angle

27.3º

Max. Ground Clearence

333 mm

Fording Depth

900 mm

OVERALL

STORAGE

OFF-ROAD

Powertrain

Drive

Intelligent All-wheel Drive

Engine & Motors

2 Motors

Engine

1.5 L Engine (Battery Generator)

Battery Type

Lithium Iron Phosphate (LFP)

Battery Capacity (kW·h)

31.7

Max. Power HP (kW)

677 (500)

Max. Torque (N·m)

848

0-100km/h Acceleration (s)

5.2

Electric Range WLTC (km)

110

Combined Range WLTC (km)

1,113

DC Fast Charging (min)

15 (20%-80%)

Dimensions & Capacities

Length X Width X Height (mm)

5,100 X 1,998 X 1,899

Wheelbase (mm)

3,005

Front/Rear Wheel Track (mm)

1710 / 1707 | 1720 / 1717

Seats Layout

2+3

Trunk Capacity (Litres)

828 : 2112

Curb Weight (kg)

2,817 | 2,909

Fuel Tank Capacity (Litres)

Off-road Capabilities

Vehicle Height Adjustment Range (mm)

— | -45 : +105

Min. Ground Clearance (Standard/Off-road)

222 | 228/333

Approach Angle-Off-road (Degree)

30.0 | 30/37.7

Departure Angle- Off-road (Degree)

30.0 | 30/37

Breakover Angle Off-road (Degree)

19.0 | 19/27.3

Max. Rear Wheel Steering Angle (Degree)

— | 10.0

Min. Turning Radius (m)

6.2 | 5.2

Max. Wading Depth (mm)

700 | 900

Max. Climbing Gradient

100%

Off-road Performance

M ATS™ System

ALL Terrain - Intelligent Driving Modes

Vehicle Motion Control System

✔

Intelligent Wading Sensing System

— | ✔

Intelligent Night Vision System

—

Off-Road Mode

Deep Snow / Light Snow / Mud / Rock / Sand / Wading / Auto

Crab-walk Mode

— | ✔

Crawl Mode

✔

Mengshi Intelligent E-Lock

✔

Front & Rear Differential Lock

✔ | —

4 Hooks (1 Front + 1 Rear)

✔

External Output 6kW

✔

Suspensions & Tires

Front & Rear Double-Wishbone Independent Suspension

✔

Adaptive Smart Air Suspension

— | ✔

Dynamic Suspension Damping Control (CDC)

— | ✔

Front & Rear Ventilated Disc Brake

✔

18-Inch Alloy Wheels with WestLake Custom 265/65 R18 Highway Tires

✔ | —

20-Inch Alloy Wheels with Continental® CrossContact RX 275/60 R20 Highway Tires

— | ✔

Exterior Features

LED Front Headlamp Assembly

✔

Adaptive Matrix Headlights (ADB)

— | ✔

Electrically Adjustable Headlight Height

✔ | ✔ (Auto)

LED Rear Combination Taillights

✔

LED Rear Fog Light

✔

LED High-Mounted Brake Light

✔

Off-Road Style Bumper

✔ | —

Urban Style Bumper

— | ✔

Illuminated Grille

— | ✔

Panoramic Sunroof with Power Sunshade

— | ✔

Frameless Exterior Mirrors (Power Adjustable, Power Folding, Heated, Memory Function)

✔

Soft-Close Doors with Full-Cabin Sound Insulation (All Five Doors)

Power Soft-Close Liftgate | ✔

Front Windshield & Front Side Windows (Heat-Insulating, Noise-Reducing)

✔

One-Touch Power Windows with Anti-Pinch Function (All Four Doors)

✔

Fixed Side Step

✔ | —

Power Retractable Side Step

— | ✔

Roof Rack

✔

Interior Features

Multi-Function Steering Wheel

Leather | NAPPA Leather

4-Way Adjustable Steering Wheel

✔

PU Leather Seats

✔ | —

Nappa Leather Seats

— | ✔

Headliner Material

Fabric | Eco-Friendly Suede

Flight-Style Paddle

✔

12-Way Power Adjustable Driver Seat with 4-Way Lumbar Support

✔

10-Way Power Adjustable Front Passenger Seat with 4-Way Lumbar Support

Without Lumbar Support | ✔

Driver Seat Massage Function

— | ✔

Front Passenger Seat Massage Function

— | ✔

Front Seats with Memory, Heating & Ventilation

Without Ventilation and Heating | Without Heating

Boss Key (Rear Seat Control of Front Passenger Seat)

— | ✔

M-SOUND Premium Audio Cabin

✔ 12 | —

Dynaudio® HiFi Audio Cabin

— | ✔ 18

ENC (Electronic Noise Cancellation)

✔

256-Color LED Ambient Lighting

— | ✔

Dual-Zone Automatic Climate Control

✔

Air Purification System

✔

Negative Ion Generator

✔

In-Cabin PM2.5 Filtration & Monitoring

✔

Antibacterial & Anti-Allergy Activated Carbon Multi-Functional Filter

✔

Smart Dual-Mode Refrigerator (Cooling & Heating)

— | ✔

Front Wireless Phone Charger (50W, Air-Cooled)

✔ 1

Type-A USB Ports (Front & Second Row)

✔ 2

Type-C USB Ports (Instrument Panel, Front & Second Row)

✔ 3

12V Power Outlet (Front & Trunk)

✔ 2

220V Power Outlet (Second Row & Trunk)

✔ 2

Intelligent Cockpit

10.25-Inch Digital Instrument Cluster

✔

15.6-Inch Central Control Touchscreen

✔

W-HUD Enhanced Head-Up Display System

— | ✔

Flight-Style Mode Selector Knob (Off-Road Mode Switching)

✔

Streaming Media Rearview Mirror

✔

Rear Seat Control Touchscreen

— | ✔

Quad-Zone Intelligent Voice Control System

✔

Carplay/AndroidAuto

✔

Keyless Entry

✔

Safety Features

Front Airbags

✔ 2

Front Side Airbags

✔ 2

Second-Row Side Airbags

— | ✔ 2

Full-Length Side Curtain Airbags (30s Pressure Retention)

✔ 2

Front Seatbelt with Pretensioner and Load Limiter

✔

Second-Row 3-Point Seatbelts

✔

Tire Pressure Monitoring System (TPMS)

✔

Auto-Lock Upon Vehicle Exit

✔

E-CALL Emergency Call System

✔

ISOFIX Child Safety Seat Anchors

✔

Underbody Protection Plate / Chassis Guard Plate

✔

Intelligent Driving Assistance — Hardware Configuration

Ultrasonic Radar

✔ 4 | ✔ 8

Millimeter-Wave Radar

✔ 3

High-Resolution Perception Camera (Integrated Unit)

✔ 1

Camera Module

✔ 4

L2-Level Intelligent Driving Assistance

360° Surround View System (AVM - Around View Monitor)

✔

Transparent Chassis View / See-Through Chassis View

✔

Adaptive Cruise Control (ACC)

✔

Intelligent Cruise Assist (ICA)

✔

Forward Collision Warning (FCW)

✔

Autonomous Emergency Braking (AEB)

✔

Rear Collision Warning (RCW)

✔

Rear Cross Traffic Alert / Braking (RCTA/B)

✔

Door Open Warning (DOW)

✔

Lane Departure Warning (LDW)

✔

Intelligent Speed Limit Control (ISLC)

✔

Blind Spot Detection (BSD)

✔
